Hot Galvanized Steel Electric Utility Power Transmission Tower Round 20 M

বড় ইমেজ : Hot Galvanized Steel Electric Utility Power Transmission Tower Round 20 M

পণ্যের বিবরণ:

Place of Origin:	China
পরিচিতিমুলক নাম:	MilkyWay
সাক্ষ্যদান:	ISO9001/BV/
Model Number:	Steel Electric Power Pole

প্রদান:

Minimum Order Quantity:	1 pcs
মূল্য:	Negotiation
Packaging Details:	As customer request
Delivery Time:	20 working days after received your payment
Payment Terms:	T/T, L/C at sight
Supply Ability:	300pcs per day

যোগাযোগ

বিস্তারিত পণ্যের বর্ণনা

Product Name:	Steel Electric Power Poles	Application:	Electric Power Distribution
Surface treatment:	galvanization	Welding standard:	AWS D 1.1 /BS EN 1011-1,BS EN 1011-2
Galvanization standard:	ASTM A 123	Lift time:	50 years
Warranty:	15 years
লক্ষণীয় করা:	transmission line poles , electric power pole

Hot Galvanized Round 20 M Steel Electric Utility Power Transmission Tower Monopo Hardware 4mm for Power Distribution

Specification:

Distribution Range
Product Code	Length	ULS	Pole Dimension
Product Code	Length	ULS	Top	Base
11M 13.5KN	11M	13.5kN	160	328
12.5M 12KN	12.5M	12KN	160	340
12.5M 16KN	12.5M	16KN	180	380
12.5M 24KN	12.5M	24KN	200	420
14M 16KN	14M	16KN	190	402
14M 24KN	14M	24KN	210	465
15.5M 12KN	15.5M	12KN	160	405
15.5M 24KN	15.5M	24KN	210	500
Note:Tapered 12-sided, direct buried Pole deflection less than 5% of pole height at 50% ULS

Sub Transmission Range
Product Code	Length	ULS	Pole Dimension
Product Code	Length	ULS	Top	Base
18.5M 24KN	18.5M	24KN	210	660
18.5M 40KN	18.5M	40KN	260	730
21M 40KN	21M	30KN	220	697
21M 40KN	21M	40KN	260	795
24M 30KN	24M	30KN	220	755
24M 40KN	24M	40KN	300	760
Note:Tapered 12-sided, direct buried

Descripition of material:

1. Poles are made by the high-quality metal plants,which were molded into the multi-row cone-shaped vertical steel barwith hot galvanized anti-corrosion treatment
2. Light plate frame is made by high-quality stainless steel
3. Fastened bolts and nuts of stainless steel

Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm²
Q235B/A36, Minimum Yield Strength ≥ 235 N/mm²
As well as Hot rolled coil from ASTM A572 GR65, GR50, SS400

Some of the advantages of steel poles over wood poles are as follows:

Lighter - steel poles are significantly lighter than wood poles

More consistent - steel poles do not vary in dimension

Longer service life – steel poles are not vulnerable to insects, woodpeckers or other wildlife

Cost competitive – steel poles are becoming much more affordable as an alternative to wood

Recyclable – steel poles are recyclable after their service life

Different appearances - steel poles are available painted, with a traditional galvanized finish, or in weathering steel

With the advantages of steel, utility companies continue to rely on steel distribution poles in place of wood.

Hot Galvanized Steel Electric Utility Power Transmission Tower Round 20 M 0

Welding:

Advanced submerge-arc welding and CNC welding equipment. It has past flaw testing, internal and external double welding makes the welding beautiful in shape. It confirms with the international welding standard of CWB and AWS D 1.1

Galvanization
Standard:NFA91121
Average thickness of the galvanization:Not less than 86μm.

Installation
- Remove all the equipment on the pole during Assembly.
- Circle a sling around th epole shaft of each section.
- Fix the sling on top section to one pulley block.
- The sling on the bottom section is tightly fixed and fixed at the center of gravity.
- Make the steel pole vertical by tighten the sling of the top section.
- Fix the steel pole.
- Remove the sling.
