Milky Way Transmission Electrical Steel Tubular Pole Self Supporting / Metal Utility Poles

বড় ইমেজ : Milky Way Transmission Electrical Steel Tubular Pole Self Supporting / Metal Utility Poles

পণ্যের বিবরণ:

Place of Origin:	China,Jiangsu
পরিচিতিমুলক নাম:	MilkyWay
সাক্ষ্যদান:	ISO9001/BV/
Model Number:	Steel Tubular Pole

প্রদান:

Minimum Order Quantity:	1 pcs
মূল্য:	Negotiation
Packaging Details:	As customer request
Delivery Time:	20 working days after received your payment
Payment Terms:	T/T, L/C at sight
Supply Ability:	300pcs per day

যোগাযোগ

বিস্তারিত পণ্যের বর্ণনা

Welding:	AWS D1.1	material:	Q345
Delivery:	20-30 days	Supply Ability::	2000pcs per week
পরিচিতিমুলক নাম:	MilkyWay	Certificate:	ISO9001:2008
Tolerance:	+/-2%
লক্ষণীয় করা:	commercial light poles , metal light pole

Milky Way Transmission Electrical Steel Tubular Pole Self Supporting / Metal Utility Poles

Type	Straight Pole ,Tensile Pole ,Turn Pole
Suit for	Electricity distribution
Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 , SS400, SS490, to ST52-
Lamp power	20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz
Torlance of the dimenstion	+- 2%
Power	10 KV ~550 KV
Safety Factor	Safety factor for conducting wine : 8 Safety factor for grounding wine : 8
Design Load in Kg	300~ 1000 Kg appliced to 50cm from the to pole
Marks	Nane palte through rivert or glue ,engrave ,emboss as per customer requirement
Surface treatment	Hot dip galvanized Following ASTM A 123,color polyester power or any other standard by client required.
Joint of Poles	Insert mode,innerflange mode,face to face joint mode .
Design of pole	Against earthquake of 8 grade
Wind Speed	160 Km/Hour
Minimum yield strength	355 mpa
Minimum ultimate tensile strength	490 mpa
Max ultimate tensile strength	620 mpa
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint
Welding	We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness	1 mm to 30 mm
Production Process	Rew material test → Cuttingj →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages
Packages	Our poles as normal cover by Mat or straw bale at the top and bottom , anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.

Inspection:

Milky Way Transmission Electrical Steel Tubular Pole Self Supporting / Metal Utility Poles 0

Description:

Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on.

We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia and so on.

Milky Way Transmission Electrical Steel Tubular Pole Self Supporting / Metal Utility Poles 1

Our Servises:

1 Reply your inquiry in 24 working hours.

2 Experienced staffs answer all your questions in fluent English.

3 Customized design is available. UEM&UBM are welcomed.

4 Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.

5 Special discount and protection of sales are provided to our distributor.

6 Professional factory : We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.

7 Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.

8 As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.

if you have any question or need additional information ,pls feel free to contact me !
